FX58 - (9/98-) Drive Line

Key

Ref	Description
1	CONTROL SHAFT
2	RING
3	SNAP RING,M110, Int
4	BEARING ASSY,60 mm ID x 110 mm OD x 28 mm
5	SHIM,1mm Thk
6	SPACER
6	BUSHING
7	HYDRAULIC HOSE
7	HYDRAULIC HOSE
8	BOLT,Hex, M10 x 60, 8.8, Full Thd
8	SCREW,Hex, M12 x 60, 8.8, Full Thd
8	SET SCREW,Hex Soc, M16 x 60
9	SEAL
9	SEAL
9	WASHER,M16 x 30 x 3
10	SNAP RING,M50, Ext
10	RING, SNAP
11	BEARING ASSY
12	CONTROL SHAFT
13	GEAR
14	SCREW
14	SCREW
15	BALL BEARING,60 mm ID x 110 mm OD x 44 mm
16	BEARING LOCK NUT
17	GASKET
18	O-RING,110mm ID x 3mm Width
19	COVER
20	SCREW,Hex Soc Hd, M8 x 25, 8.8
21	WASHER
22	WASHER
23	SHIM,0.1mm Thk
23	SHIM,M50 ID x 62 OD x .3 Thk
23	SHIM,M50 ID x 62 OD x .3 Thk (pack of 2)
23	SHIM,0.5mm Thk

MalpasDirect - Replacement Tractors Parts

Diagram

Located in:

FX Series Parts / FX58 - (9/98-) / Drive Line /

Ref	Part No. and Description	Price (GBP) VAT (20%)	Min.(Qty)	Add
1	84021944 CONTROL SHAFT for all New Holland FX Forager Harvesters models (Job Qty: 1) Part superseded - limited stock Shipping Costs...	Call Ex VAT	1
2	84021949 RING for all New Holland FX Forager Harvesters models (Job Qty: 1) Part superseded - limited stock Shipping Costs...	Call Ex VAT	1
3	301652 SNAP RING,M110, Int for all New Holland FX Forager Harvesters models (Job Qty: 1) Part superseded - limited stock Shipping Costs...	Call Ex VAT	2
4	84021946 BEARING ASSY,60 mm ID x 110 mm OD x 28 mm - this part has been superceded by 428162 (Job Qty: 1) Part superseded - limited stock Shipping Costs...	Call Ex VAT	1
5	556831 SHIM,1mm Thk for FX28/30/38/40/48/50/58/60 (Job Qty: AR) Part superseded - limited stock Shipping Costs...	Call Ex VAT	5
6	84021947 SPACER for FX28/300/375/38/450/48/58 , Serial Range: -C173 (Job Qty: 2) Part superseded - limited stock Shipping Costs...	Call Ex VAT	1
6	84429247 BUSHING for FX28/30/38/40/48/50/58/60 , Start Serial: D174 (Job Qty: 1) Part superseded - limited stock Shipping Costs...	Call Ex VAT	1
7	84074169 HYDRAULIC HOSE for FX28/38/48/58 , Serial Range: -C173,USE SPECIAL TOOL FOR MOUNTING (Job Qty: 1) Part superseded - limited stock Shipping Costs...	Call Ex VAT	1
7	84320145 HYDRAULIC HOSE for FX28/30/38/40/48/50/58/60 , Start Serial: D174,USE SPECIAL TOOL FOR MOUNTING (Job Qty: 1) Part superseded - limited stock Shipping Costs...	Call Ex VAT	1
8	86977775 BOLT,Hex, M10 x 60, 8.8, Full Thd for FX28/300/375/38/450/48/58 , Serial Range: -C173 (Job Qty: 1) Part superseded - limited stock Shipping Costs...	Call Ex VAT	5
8	309086 SCREW,Hex, M12 x 60, 8.8, Full Thd for all New Holland FX Forager Harvesters models , Serial Range: -F174201 (Job Qty: 1) Part superseded - limited stock Shipping Costs...	Call Ex VAT	2
8	84607596 SET SCREW,Hex Soc, M16 x 60 for FX28/30/38/40/48/50/58/60 , Start Serial: D202 (Job Qty: 1) Part superseded - limited stock Shipping Costs...	Call Ex VAT	1
9	84021930 SEAL for FX28/300/375/38/450/48/58 SEALRING, Serial Range: -C173 (Job Qty: 1) Part superseded - limited stock Shipping Costs...	Call Ex VAT	5
9	84011379 SEAL for all New Holland FX Forager Harvesters models SEALRING, Serial Range: -F174201 (Job Qty: 1) Part superseded - limited stock Shipping Costs...	Call Ex VAT	2
9	140020 WASHER,M16 x 30 x 3 for FX28/30/38/40/48/50/58/60 , Start Serial: D202 (Job Qty: 1) Part superseded - limited stock Shipping Costs...	Call Ex VAT	2
10	370008 SNAP RING,M50, Ext - this part has been superceded by 8603209 (Job Qty: 1) Part superseded - limited stock Shipping Costs...	Call Ex VAT	1
10	8603209 RING, SNAP for all New Holland FX Forager Harvesters models (Job Qty: 1) Part superseded - limited stock Shipping Costs...	Call Ex VAT	1
11	84021945 BEARING ASSY for all New Holland FX Forager Harvesters models (Job Qty: 1) Part superseded - limited stock Shipping Costs...	Call Ex VAT	1
12	84021934 CONTROL SHAFT for all New Holland FX Forager Harvesters models (Job Qty: 1) Part superseded - limited stock Shipping Costs...	Call Ex VAT	1
13	84021935 GEAR for all New Holland FX Forager Harvesters models (Job Qty: 1) Part superseded - limited stock Shipping Costs...	Call Ex VAT	1
14	84021936 SCREW - this part has been superceded by 86512142 (Job Qty: 8) Part superseded - limited stock Shipping Costs...	Call Ex VAT	1
14	86512142 SCREW (Job Qty: 8) Part superseded - limited stock Shipping Costs...	Call Ex VAT	1
15	84021937 BALL BEARING,60 mm ID x 110 mm OD x 44 mm for all New Holland FX Forager Harvesters models (Job Qty: 2) Part superseded - limited stock Shipping Costs...	Call Ex VAT	1
16	84021938 BEARING LOCK NUT for all New Holland FX Forager Harvesters models M60x2 (Job Qty: 1) Part superseded - limited stock Shipping Costs...	Call Ex VAT	1
17	84021941 GASKET - this part has been superceded by 84074274 (Job Qty: 1) Part superseded - limited stock Shipping Costs...	Call Ex VAT	1
18	84021940 O-RING,110mm ID x 3mm Width for all New Holland FX Forager Harvesters models (Job Qty: 1) Part superseded - limited stock Shipping Costs...	Call Ex VAT	1
19	84021939 COVER for all New Holland FX Forager Harvesters models (Job Qty: 1) Part superseded - limited stock Shipping Costs...	Call Ex VAT	1
20	120163 SCREW,Hex Soc Hd, M8 x 25, 8.8 for all New Holland FX Forager Harvesters models (Job Qty: 6) Part superseded - limited stock Shipping Costs...	Call Ex VAT	1
21	84023741 WASHER for all New Holland FX Forager Harvesters models (Job Qty: 1) Part superseded - limited stock Shipping Costs...	Call Ex VAT	1
22	84100556 WASHER for FX28/30/38/40/48/50/58/60 , Start Serial: D174 (Job Qty: 1) Part superseded - limited stock Shipping Costs...	Call Ex VAT	1
23	539448 SHIM,0.1mm Thk for FX28/30/38/40/48/50/58/60 , Start Serial: D174 (Job Qty: AR) Part superseded - limited stock Shipping Costs...	Call Ex VAT	1
23	539449 SHIM,M50 ID x 62 OD x .3 Thk - this part has been superceded by 87025488 THK.: 0.3MM, Start Serial: D174 (Job Qty: AR) Part superseded - limited stock Shipping Costs...	Call Ex VAT	1
23	87025488 SHIM,M50 ID x 62 OD x .3 Thk (pack of 2) THK.: 0.3MM, Start Serial: D174 (Job Qty: AR) Part superseded - limited stock Shipping Costs...	Call Ex VAT	1
23	539450 SHIM,0.5mm Thk for FX28/30/38/40/48/50/58/60 , Start Serial: D174 (Job Qty: AR) Part superseded - limited stock Shipping Costs...	Call Ex VAT	1
				Add
