FX40 - (1/02-) Hydraulic Systems

Key

Ref	Description
1	BALL JOINT
2	COTTER PIN,M4 x 40 (pack of 10)
2	COTTER PIN,M4 x 40
3	SLOTTED NUT
4	NUT,Thin, M20 x 1.5, Cl 04
5	HYDRAULIC CYLINDER
6	NUT,13/16"-16, G2
7	BALL JOINT
7	BALL JOINT
8	HYD CONNECTOR
9	ELBOW
10	HYDRAULIC HOSE
10	HYDRAULIC HOSE,7.90 mm ID x 850.00 mm, SAE 100R1, SAE J517
11	FLEXIBLE HOSE
11	HYDRAULIC HOSE
12	HYD CONNECTOR
13	HYD. TUBE,2000 mm Length
14	TUBE NUT
15	FERRULE
16	HYD CONNECTOR
16	UNION
17	CABLE TIE,M9 x 165 or M5 x 197 (pack of 50)
17	CABLE TIE,M9 x 165 or M5 x 197
18	SEAL KIT
19	CLAMP
20	SUPPORT
21	SCREW,Hex, M6 x 45, 8.8
22	WASHER,M6
22	WASHER,M6
23	NUT,M6 x 1, Cl 8
24	COTTER PIN,M4 x 32

MalpasDirect - Replacement Tractors Parts

Diagram

Located in:

FX Series Parts / FX40 - (1/02-) / Hydraulic Systems /

Ref	Part No. and Description	Price (GBP) VAT (20%)	Min.(Qty)	Add
1	84039559 BALL JOINT for all New Holland FX Forager Harvesters models (2, 3) (Job Qty: 2) Part superseded - limited stock Shipping Costs...	Call Ex VAT	1
2	10733901 COTTER PIN,M4 x 40 (pack of 10) (Job Qty: 2) Part superseded - limited stock Shipping Costs...	Call Ex VAT	1
2	300595 COTTER PIN,M4 x 40 - this part has been superceded by 10733901 (Job Qty: 2) Part superseded - limited stock Shipping Costs...	Call Ex VAT	1
3	412103 SLOTTED NUT for all New Holland FX Forager Harvesters models M18 (Job Qty: 2) Part superseded - limited stock Shipping Costs...	Call Ex VAT	1
4	320771 NUT,Thin, M20 x 1.5, Cl 04 for all New Holland FX Forager Harvesters models (Job Qty: 2) Part superseded - limited stock Shipping Costs...	Call Ex VAT	2
5	84444432 HYDRAULIC CYLINDER for FX30/40/50/60 (18) (Job Qty: 2) Part superseded - limited stock Shipping Costs...	Call Ex VAT	1
6	331209 NUT,13/16"-16, G2 for all New Holland FX Forager Harvesters models 13/16" (Job Qty: 2) Part superseded - limited stock Shipping Costs...	Call Ex VAT	1
7	84444424 BALL JOINT (2, 24) (Job Qty: 2) Part superseded - limited stock Shipping Costs...	Call Ex VAT	1
7	84444425 BALL JOINT - this part has been superceded by 84444424 (2, 24) (Job Qty: 2) Part superseded - limited stock Shipping Costs...	Call Ex VAT	1
8	395019 HYD CONNECTOR for all New Holland FX Forager Harvesters models (Job Qty: 4) Part superseded - limited stock Shipping Costs...	Call Ex VAT	1
9	418284 ELBOW for all New Holland FX Forager Harvesters models (Job Qty: 8) Part superseded - limited stock Shipping Costs...	Call Ex VAT	1
10	734029 HYDRAULIC HOSE for all New Holland FX Forager Harvesters models (Job Qty: 2) Part superseded - limited stock Shipping Costs...	Call Ex VAT	1
10	84037312 HYDRAULIC HOSE,7.90 mm ID x 850.00 mm, SAE 100R1, SAE J517 for FX28/30/38/40/48/50/58/60 FOR NA ONLY (Job Qty: 2) Part superseded - limited stock Shipping Costs...	Call Ex VAT	1
11	84036881 FLEXIBLE HOSE for all New Holland FX Forager Harvesters models (Job Qty: 2) Part superseded - limited stock Shipping Costs...	Call Ex VAT	1
11	ZED916188 HYDRAULIC HOSE for FX28/30/38/40/48/50/58/60 FOR NA ONLY (Job Qty: 2) Part superseded - limited stock Shipping Costs...	Call Ex VAT	1
12	734031 HYD CONNECTOR for all New Holland FX Forager Harvesters models (Job Qty: 2) Part superseded - limited stock Shipping Costs...	Call Ex VAT	1
13	371539 HYD. TUBE,2000 mm Length for all New Holland FX Forager Harvesters models D= 10 (Job Qty: AR) Part superseded - limited stock Shipping Costs...	Call Ex VAT	1
14	86548975 TUBE NUT for all New Holland FX Forager Harvesters models M10 (Job Qty: 4) Part superseded - limited stock Shipping Costs...	Call Ex VAT	2
15	150014 FERRULE for all New Holland FX Forager Harvesters models (Job Qty: 4) Part superseded - limited stock Shipping Costs...	Call Ex VAT	5
16	150017 HYD CONNECTOR - this part has been superceded by 47499003 (Job Qty: 2) Part superseded - limited stock Shipping Costs...	Call Ex VAT	1
16	47499003 UNION - this part has been superceded by 47499003 (Job Qty: 2) Part superseded - limited stock Shipping Costs...	Call Ex VAT	1
17	14560287 CABLE TIE,M9 x 165 or M5 x 197 (pack of 50) FOR NA ONLY (Job Qty: 4) Part superseded - limited stock Shipping Costs...	Call Ex VAT	1
17	323597 CABLE TIE,M9 x 165 or M5 x 197 - this part has been superceded by 14560287 FOR NA ONLY (Job Qty: 4) Part superseded - limited stock Shipping Costs...	Call Ex VAT	1
18	84037236 SEAL KIT for all New Holland FX Forager Harvesters models (Job Qty: 2) Part superseded - limited stock Shipping Costs...	Call Ex VAT	1
19	433008 CLAMP for all New Holland FX Forager Harvesters models (Job Qty: 2) Part superseded - limited stock Shipping Costs...	Call Ex VAT	2
20	433101 SUPPORT for all New Holland FX Forager Harvesters models (Job Qty: 1) Part superseded - limited stock Shipping Costs...	Call Ex VAT	2
21	86977790 SCREW,Hex, M6 x 45, 8.8 for all New Holland FX Forager Harvesters models (Job Qty: 1) Part superseded - limited stock Shipping Costs...	Call Ex VAT	10
22	9824259 WASHER,M6 (Job Qty: 1) Part superseded - limited stock Shipping Costs...	Call Ex VAT	25
22	140015 WASHER,M6 - this part has been superceded by 9824259 (Job Qty: 1) Part superseded - limited stock Shipping Costs...	Call Ex VAT	1
23	353308 NUT,M6 x 1, Cl 8 for all New Holland FX Forager Harvesters models (Job Qty: 1) Part superseded - limited stock Shipping Costs...	Call Ex VAT	25
24	412685 COTTER PIN,M4 x 32 for all New Holland FX Forager Harvesters models (Job Qty: 2) Part superseded - limited stock Shipping Costs...	Call Ex VAT	5
