FX30 - (1/02-) Electrical System

Key

Ref	Description
1	BULB
2	TOGGLE SWITCH
3	TOGGLE SWITCH
4	TOGGLE SWITCH
5	PLUG
5	PLUG
6	HARVEST ROAD SWITCH
7	TOGGLE SWITCH
8	TOGGLE SWITCH
9	TOGGLE SWITCH
10	LIGHT SWITCH
11	TOGGLE SWITCH
12	TOGGLE SWITCH
13	TOGGLE SWITCH
14	TOGGLE SWITCH
15	TOGGLE SWITCH
16	TOGGLE SWITCH
17	DECAL

MalpasDirect - Replacement Tractors Parts

Diagram

Located in:

FX Series Parts / FX30 - (1/02-) / Electrical System /

Ref	Part No. and Description	Price (GBP) VAT (20%)	Min.(Qty)	Add
1	84017423 BULB for all New Holland FX Forager Harvesters models 1.2 W - 12 V (Job Qty: AR) Part superseded - limited stock Shipping Costs...	Call Ex VAT	10
2	84019743 TOGGLE SWITCH for all New Holland FX Forager Harvesters models Drive cutterhead (Job Qty: 1) Part superseded - limited stock Shipping Costs...	Call Ex VAT	1
3	84019742 TOGGLE SWITCH for all New Holland FX Forager Harvesters models 4-Wheel drive (Job Qty: 1) Part superseded - limited stock Shipping Costs...	Call Ex VAT	1
4	84019741 TOGGLE SWITCH for all New Holland FX Forager Harvesters models RPM (Job Qty: 1) Part superseded - limited stock Shipping Costs...	Call Ex VAT	1
5	5151033 PLUG (Job Qty: AR) Part superseded - limited stock Shipping Costs...	Call Ex VAT	2
5	9504368 PLUG - this part has been superceded by 5151033 (Job Qty: AR) Part superseded - limited stock Shipping Costs...	Call Ex VAT	1
6	84021351 HARVEST ROAD SWITCH for all New Holland FX Forager Harvesters models Harvest Road (Job Qty: 1) Part superseded - limited stock Shipping Costs...	Call Ex VAT	1
7	84019739 TOGGLE SWITCH for all New Holland FX Forager Harvesters models Metal detector (Job Qty: 1) Part superseded - limited stock Shipping Costs...	Call Ex VAT	1
8	84019738 TOGGLE SWITCH for all New Holland FX Forager Harvesters models Auto-pilot (Job Qty: 1) Part superseded - limited stock Shipping Costs...	Call Ex VAT	1
9	84019737 TOGGLE SWITCH for all New Holland FX Forager Harvesters models Silage (Job Qty: 1) Part superseded - limited stock Shipping Costs...	Call Ex VAT	1
10	84019736 LIGHT SWITCH for all New Holland FX Forager Harvesters models Lights (Job Qty: 1) Part superseded - limited stock Shipping Costs...	Call Ex VAT	1
11	84019735 TOGGLE SWITCH for all New Holland FX Forager Harvesters models Flashlight (Job Qty: 1) Part superseded - limited stock Shipping Costs...	Call Ex VAT	1
12	84021613 TOGGLE SWITCH for all New Holland FX Forager Harvesters models Reverse mech. (Job Qty: 1) Part superseded - limited stock Shipping Costs...	Call Ex VAT	1
13	84019734 TOGGLE SWITCH for all New Holland FX Forager Harvesters models Adjust-o-matic (Job Qty: 1) Part superseded - limited stock Shipping Costs...	Call Ex VAT	1
14	84019733 TOGGLE SWITCH for all New Holland FX Forager Harvesters models Reverse cutterhead (Job Qty: 1) Part superseded - limited stock Shipping Costs...	Call Ex VAT	1
15	84019732 TOGGLE SWITCH for all New Holland FX Forager Harvesters models Roll adj. (Job Qty: 1) Part superseded - limited stock Shipping Costs...	Call Ex VAT	1
16	84043203 TOGGLE SWITCH for all New Holland FX Forager Harvesters models High capacity hydr. (Job Qty: 1) Part superseded - limited stock Shipping Costs...	Call Ex VAT	1
17	84002722 DECAL for FX28/30/38/40/48/50/58/60 FOR NA ONLY (Job Qty: 1) Part superseded - limited stock Shipping Costs...	Call Ex VAT	1
				Add
